Sketchup Plugins



:

A comprehensive parametric library for generating precise 3D bolts, nuts, and threads with real-world 3D printing tolerances (from M2 to M450)

Usage: Accessible via the SketchUp Extensions menu or the dedicated MoGrOv Toolbar.

Downloads: 561                [ Version Updated: 2026-09-09 12:18:40 ]

:

Instantly create 3D-printable trapezoidal screws and nuts in SketchUp. Designed for woodworking clamps, mechanical jigs, and functional parts with optimized FDM tolerances.

Usage: **Plugin Usage:** You can access the tools via the top menu or the dedicated toolbar: * **Menu:** `Extensions` (or `Plugins`) > `MoGrOv TR Generator` > `Create Screw` / `Create Nut` / `Help` * **Toolbar:** `View` > `Toolbars` > `MoGrOv TR Generator` **How to use:** 1. Select a valid cylindrical geometry (a Group or a Component). 2. Click on the **Create Screw** (external thread) or **Create Nut** (internal thread) tool. 3. The plugin will automatically repair/prepare the geometry if necessary and generate a 3D-printable trapezoidal thread.

Downloads: 188                [ Version Updated: 2026-09-09 13:02:01 ]

:

robo placement: scatter up to 500 copies of a component onto surfaces with true collision detection to prevent overlapping. Includes automatic alignment to face normals.

Usage: Plugins > Robo Tools > robo Placement

Downloads: 804                [ Version Updated: 2026-09-03 20:12:31 ]


:

Round or chamfer two straight edges with a precise arc on any plane in 3D. Live preview, smart radius limits, virtual-corner support, and clean one-step undo for fast, accurate fillets

Usage: Extensions > Robo Tools > Robo Fillet. Select two converging straight edges, set Radius and Segments or enable Chamfer, preview the result live, then press Apply or Enter to create the fillet.

Downloads: 2584                [ Version Updated: 2026-09-03 20:04:50 ]


:

Automatically switch backgrounds, projections, LED/video screens, signage and scenic textures with SketchUp scenes—for theatre, stage, set, event and exhibition design.

Usage: Extensions > Scene TextureSwitch

Downloads: 41                [ Version Updated: 2026-09-01 18:11:47 ]

:

Shared library needed by many of the Fredo plugins for SU2017+. It is NOT a standalone plugin. v16.1g for bug fixing on Mac in some configurations

Usage: Window > LibFredo6 Settings...

Dependencies: Need SU2017 and above

Downloads: 3702660                [ Version Updated: 2026-09-11 17:12:08 ]


:

Restore Finder previews for a whole SketchUp library in one operation, including subfolders—no need to open each model. Also restores the current model’s icon after normal saves on macOS.

Usage: Extensions > Repair a folder of SketchUp Finder icons… (includes subfolders)

Downloads: 58                [ Version Updated: 2026-09-07 13:36:34 ]

:

Bakes component/group scale permanently into geometry, resetting transform to 1.0. Optional Tri-Planar World/Fit texture re-projection (V-Ray-style), works even on already-unit-scale objects and group-painted f.

Usage: Plugins > RoboTools > robo Scale Definition

Downloads: 1028                [ Version Updated: 2026-09-07 19:32:43 ]


:

A view pie at your cursor. Switch to any standard view, snap to the nearest one, align to a face, or lock the camera in place. Free.

Usage: Extensions > VirgoScript > Viewpie

Downloads: 23                [ Version Updated: 2026-09-10 02:25:17 ]

:

Robo Group to Component is a SketchUp plugin (RoboTools suite) that converts groups into proper component definitions, automatically merging identical groups into shared, instanced components while keeping geometrically or texturally different groups as

Usage: Quick Start Select the groups you want to convert, or select nothing to scan the entire scene. The plugin auto-analyzes on open. Results appear immediately in Detected Groups. Click Re-Analyze after changing the selection. Review the detected groups. Double-click any row to rename it. Click Convert. All groups are replaced with components in a single undoable step

Downloads: 649                [ Version Updated: 2026-09-03 20:38:57 ]


:

One click turns your model into a link and a QR code your client opens on their phone. Nothing to install. Stand a building on their table, lift its roof to see inside, place a chair at 1:1 in the room, measure it. Free plan, no card.

Usage: Plugins > Smart Web Export > Export Model

Downloads: 209                [ Version Updated: 2026-09-11 11:23:30 ]


:

Associative real-shape holes that follow the cutter when you move, copy, array or resize it — plus edge-to-edge part positioning with live on-screen dimensions. Built for architectural workflows in SketchUp Pro.

Usage: Extensions > CGS Tools (also available on toolbar and right-click menu)

Downloads: 92                [ Version Updated: 2026-09-07 21:54:05 ]

:

Control and time a theatrical revolve directly inside a SketchUp model.

Usage: Name a group/component #Turntable#, then Extensions > Turntable

Downloads: 41                [ Version Updated: 2026-09-01 19:43:28 ]

:

Manage all section planes in one panel, even nested ones. Select, activate, isolate, rename and sync sections across Model, Groups and Components without losing your view or breaking SketchUp's one-active-section-per-context rule.

Downloads: 84                [ Version Updated: 2026-09-04 13:57:27 ]


:

Browse, install and manage your SketchUp Extensions & Sketchucation Licenses in SketchUp. Access >900 RBZs. Install, enable & disable Plugins/Extensions, with lots of utilities too... If upgrading, install then restart SketchUp. Best with >v2017 or newer.

Usage: Extensions > SketchUcation > .....

Downloads: 2566305                [ Version Updated: 2026-09-04 17:33:32 ]

:

Keep SketchUp models light and responsive by turning heavy geometry into smart external proxies you can restore at any time. Robo-Proxy-Manager-Overview.

Usage: Extensions > Robo Proxy Manager > Manage proxies for heavy geometry by exporting full‑resolution components to external .skp assets and restoring them when needed.

Downloads: 212                [ Version Updated: 2026-09-09 08:48:37 ]


:

Automates the 100x scaling workaround for native SketchUp Solid Tools. It prevents disappearing faces and non-manifold errors when modeling small details for 3D printing, such as threads and custom fasteners.

Usage: View > Toolbars > MoGrOv Safe Solids

Dependencies: View > Toolbars > MoGrOv Safe Solids (Select an operation icon, then click the first and second component)

Downloads: 87                [ Version Updated: 2026-09-09 12:21:05 ]

:

Automate gear generation in SketchUp! Create perfectly meshed spur, internal, and bevel gears with smart auto-alignment, true involute profiles, and backlash control. Outlines are welded curves, ready for the Push/Pull tool.

Usage: View > Toolbars > Easy Gear

Downloads: 183                [ Version Updated: 2026-09-09 12:25:36 ]

:

robo tangent: draws common tangents between two arcs/circles. Click first arc (red), second arc (blue) → move mouse: nearest tangent highlights green → click to draw. Esc cancels.

Usage: Plugins > Robo Tools > robo_tangent

Downloads: 687                [ Version Updated: 2026-09-03 20:19:33 ]


:

robo Spacing: Tool: Distribute components or groups along any line or curve (including closed loops). Features precise spacing, random rotation, and real-time previews. Before installing this version, uninstall the old version. https://youtu.be/fpqWHCiHYf

Usage: Plugins > Robo Tools > robo_Spacing_tool

Downloads: 2352                [ Version Updated: 2026-09-03 20:17:09 ]
