Quick-Start Guide

Activate MAJBeam Open the MAJBeam tab and click the Beam icon.

Set Beam Parameters Enter the following before placing the beam:

Beam Width – thickness of the beam

Beam Height – vertical height of the beam

Neck First – size of the first neck section

Neck Second – size of the second neck section

Stirrup Distance – spacing between stirrups

Stirrup Size – thickness of stirrups

Ribar Size – diameter of rebars

Ribar Number – number of rebars inside the beam

Place the Beam

Click the start point where the beam begins.

Click the end point where the beam ends. The beam will be created automatically.

YouTube: https://youtu.be/xB0veSgs_TA Quick-Start Guide

Activate MAJBeam Open the MAJBeam tab and click the Beam icon.

Set Beam Parameters Enter the following before placing the beam:

Beam Width – thickness of the beam

Beam Height – vertical height of the beam

Neck First – size of the first neck section

Neck Second – size of the second neck section

Stirrup Distance – spacing between stirrups

Stirrup Size – thickness of stirrups

Ribar Size – diameter of rebars

Ribar Number – number of rebars inside the beam

Place the Beam

Click the start point where the beam begins.

Click the end point where the beam ends. The beam will be created automatically.

MAJ_Beam – Plugin Documentation

Version: 2026 Author: Majid Mahmoudi

Overview

MAJBeam is a SketchUp plugin designed to help architects, engineers, and designers quickly create reinforced concrete beams with precise dimensions and structural details. It supports both simple and complex beams, including neck sections and rebar arrangements. The plugin is fully compatible with other MAJ Architect tools like MAJWall, ensuring seamless integration into your building model workflow.

Features

Create beams with exact Width, Height, and Elevation.

Define Neck First and Neck Second sections for stepped beams.

Automatically place Stirrups with custom spacing and size.

Add Rebars with specific diameter and quantity.

Align beams along edges, lines, or existing geometry.

Generate beams as grouped entities for easy editing, moving, or copying.

Fully integrated into MAJ Architect workflow.

Quick-Start Guide

Activate MAJBeam Open the MAJBeam tab and click the Beam icon.

Set Beam Parameters Enter the following before placing the beam:

Beam Width – thickness of the beam

Beam Height – vertical height of the beam

Neck First – size of the first neck section

Neck Second – size of the second neck section

Stirrup Distance – spacing between stirrups

Stirrup Size – thickness of stirrups

Ribar Size – diameter of rebars

Ribar Number – number of rebars inside the beam

Place the Beam

Click the start point where the beam begins.

Click the end point where the beam ends. The beam will be created automatically.

Detailed Instructions Setting Parameters

Beam Width & Height: Determines the main dimensions of the beam.

Neck Sections: Optional steps in the beam’s profile, used for structural detailing.

Stirrups: Vertical reinforcement; define spacing and thickness to match design standards.

Rebars: Horizontal reinforcement inside the beam; set diameter and number.

Placement

The beam aligns automatically between the start and end points.

Beams are created as groups, allowing you to modify or copy them without affecting other geometry.

Editing

You can edit parameters and reposition beams at any time.

The plugin ensures that rebar and stirrup placements update automatically when beam dimensions change.

Tips & Best Practices

Always set beam dimensions before placing the beam.

Use snap to edge or endpoint in SketchUp for precise alignment.

Combine MAJBeam with MAJWall to model beams embedded in walls.

For complex models, create beams in separate layers for easier management.

Compatibility

Works with SketchUp 2023–2026 (Windows & Mac).

Compatible with all other MAJ Architect plugins.

Support

For questions, tutorials, or technical support, please contact: Email: partban@gmail.com

MAJ_Beam – Release Notes (2026) New Features

Create reinforced concrete beams with full parameter control.

Define Beam Width and Beam Height for accurate structural modeling.

Support for Neck First and Neck Second sections.

Add Stirrups with customizable distance and size.

Insert Rebars with specific diameter and number inside the beam.

Automatic alignment between selected start and end points.

Beams are generated as groups for easy editing, copying, or moving.

Improvements

Optimized beam creation workflow: dimensions are set before placement.

Improved integration with other MAJ Architect plugins like MAJ_Wall.

Automatic adjustment of stirrups and rebars when beam dimensions are modified.

Enhanced precision in 3D placement and snapping to edges or points.

Bug Fixes

Fixed occasional misalignment of beams when placed on angled surfaces.

Corrected rebar spacing calculation for small beams.

Resolved display issues with stepped neck sections in SketchUp 2026.

Notes

Ensure beam parameters are set before placing the beam.

Works with SketchUp 2023–2026 on both Windows and Mac.
